S | M | L | XL | |||||||
---|---|---|---|---|---|---|---|---|---|---|
ST | Zitbuishoogte | 450 | 480 | 510 | 545 | |||||
TT | Bovenbuislengte | 535 | 550 | 565 | 585 | |||||
HT | Balhoofdhoogte | 150 | 175 | 200 | 220 | |||||
HR | Standaard cockpithoogte | 235 | 260 | 285 | 305 | |||||
HR | Maximale cockpithoogte | Van 205 tot 240 | Van 230 tot 265 | Van 255 tot 290 | Van 275 tot 305 | |||||
SA | Zitbuishoek | 74 | 74 | 74 | 74 | |||||
AH | Balhoofdhoek | 71 | 71 | 71 | 71 | |||||
CS | Lengte achtervork | 429 | 429 | 429 | 429 | |||||
SK | Stack | 577 | 597.5 | 621.5 | 640 | |||||
RE | Reach | 369.5 | 378.5 | 387 | 401.5 | |||||
BB | BB drop | 78 | 75 | 75 | 75 | |||||
LE | Wielbasis | 1016 | 1034 | 1050 | 1071.5 | |||||
RF | Vork offset | 50 | 50 | 50 | 50 | |||||
Stuurpen TK-278A |
||||||||||
Lengte fietser | Van 158 tot 164 | Van 165 tot 170 | Van 171 tot 174 | Van 175 tot 178 | Van 179 tot 182 | Van 183 tot 185 | Van 186 tot 189 | Van 190 tot 193 | Van 194 tot 197 | |
Stuurpenlengte | 60 | 80 | 80 | 90 | 90 | 100 | 100 | 110 | 120 | |
Stuurbreedte | 400 | 400 | 420 | 420 | 420 | 420 | 440 | 440 | 440 | |
Lengte van de cranks | 170 | 170 | 172.5 | 172.5 | 172.5 | 172.5 | 175 | 175 | 175 |
