S | M | L | XL | |||||||
---|---|---|---|---|---|---|---|---|---|---|
ST | Zitbuishoogte | 475 | 505 | 535 | 570 | |||||
TT | Bovenbuislengte | 546 | 561 | 576 | 591 | |||||
HT | Balhoofdhoogte | 140 | 160 | 185 | 205 | |||||
HR | Standaard cockpithoogte | 225 | 245 | 270 | 290 | |||||
HR | Maximale cockpithoogte | Van 195 tot 230 | Van 215 tot 250 | Van 240 tot 275 | Van 260 tot 295 | |||||
SA | Zitbuishoek | 71.9 | 72 | 72 | 72 | |||||
AH | Balhoofdhoek | 68.9 | 69.3 | 70 | 70 | |||||
CS | Lengte achtervork | 430 | 430 | 430 | 430 | |||||
SK | Stack | 578 | 598 | 625 | 644 | |||||
RE | Reach | 357 | 367 | 373 | 382 | |||||
BB | BB drop | 60 | 60 | 60 | 60 | |||||
LE | Wielbasis | 1038 | 1051 | 1059 | 1075 | |||||
RF | Vork offset | 51 | 51 | 51 | 51 | |||||
Stuurpen TK-278A |
||||||||||
Lengte fietser | Van 158 tot 164 | Van 165 tot 170 | Van 171 tot 174 | Van 175 tot 178 | Van 179 tot 182 | Van 183 tot 186 | Van 187 tot 190 | Van 191 tot 195 | Van 196 tot 200 | |
Stuurpenlengte | 60 | 70 | 80 | 90 | 90 | 100 | 100 | 110 | 120 | |
Stuurbreedte | 580 | 580 | 580 | 580 | 580 | 580 | 580 | 580 | ||
Lengte van de cranks | 170 | 170 | 172.5 | 172.5 | 172.5 | 172.5 | 175 | 175 | 175 |
